14MM-12DAB-FM - 12x DAB/DAB+ or FM In to IP or Analogue Out Receiver
Front View

12x DAB/DAB+ or FM In to IP or Analogue Out Receiver

14MM-12DAB-FM

Headend Equipment

Matchmaster has a full range of Headend equipment from entry level to complex systems, including engineering support and system designs. Matchmaster can offer simple Channel Filters with AGC through to complex DVB modules for any type of broadcast including Encoders, Modulators & Transmodulators for DVB-T, DVB-C, DVB-S/S2, IP, ASI, SDI, FM and many more.
View More Headend Equipment

Features and Benefits

  • 12 x DAB/DAB+ or FM inputs to IP or analogue outputs
  • For operation in SMATV and cable TV networks
  • IP SPTS output in UDP/RTP
  • Web browser user interface with built in IP switch
  • Line and headphone compatible audio monitor output
  • Can be used with Chameleon or Tangram to create DVBT output for radio insertion to TV systems

Find a Stockist Now


Pack Quantity

Inner: 1 box of 1 piece

Specifications

Input
12 separate 75 Ω F-connectors
FM Frequency 76-108 MHz
Signal level See figure 1
Sensitivity See figure 1
THD+N See figure 1
Selectivity, adjacent channel typical 50 dB
Supported de-emphasis 50 µs
RDS support on request
DAB/DAB+ Frequency 168-240 MHz
Signal level See figure 1
Sensitivity See figure 1
Selectivity, adjacent channel typical 46 dB
Output
IP 10/100/1000 Mbit RJ45 connector
UDP and RTP
Analog 3.5 mm phono jack (TRRS connector with left channel on tip, right channel on ring 1. Ring 2 and sleeve connected to ground).
Accepted loads: 16 Ω-10 k Ω
Voltage: Adjustable, nominal 0.95 VP-P*
Miscellaneous
Mounting 19" rack
Mechanical dimensions 483 x 44 x 166/184 mm **
Weight 2,05 kg
Operating temperature 0-40 °C
Operating humidity <95%, non-condensing
Packaged dimensions 510 x 95 x 340 mm
Packaged weight 2,55 kg
Encoding
Audio coder MPEG-1, layer II stereo at 192 kbit/s
Audio sample rates 48 kHz
Packaged into an MPEG transport stream
Management
Web UI via the 10/100/1000 Mbit RJ45 connector
Software upgradeable via the web UI
Power Supply
Connector IEC-60320 C14
Voltage 85-264 VAC 50/60 Hz
Consumption < 15 W
Typical SINAD and BER vs Level (Figure 1)
Figure 1
* See software manual for more information
** Excluding/including connectors
